CAN logger & telemetry
A rugged logger built into every Actium kit — or integrated into your own vehicle — and a SaaS portal that turns the data into reports, alerts and one fleet-wide view.
2× isolated CAN FD
Two galvanically isolated CAN FD channels log every frame on the bus — no sampling, no ground loops, listen-only capable.
Power-safe storage
512 MB of industrial SLC NAND, engineered to ride out ignition cycles and cold cranks without losing a frame.
LTE-M / NB-IoT + Wi-Fi
Cellular uplink with built-in eSIM — no SIM tray to service — plus dual-band Wi-Fi for high-bandwidth sync at the depot. GNSS built in.
J1939 / CANopen decode
Upload a DBC and see engineering units, not hex. Native J1939 and CANopen support.
Fleet dashboard
Every vehicle, drive and fault code in one view. Alerts when a parameter drifts out of band.
Secure OTA
Retask a logger in the field — channels, filters, triggers and firmware over the air, on hardware with secure boot and encrypted flash.
| CAN channels | 2× CAN FD, galvanically isolated |
| Storage | 512 MB industrial SLC NAND |
| Cellular | LTE Cat-M1 / NB-IoT · eSIM |
| GNSS | Integrated |
| Wi-Fi / BLE | Dual-band Wi-Fi · BLE |
| Antennas | 3× external SMA (cell / GNSS / Wi-Fi) |
| Digital I/O | 4× DI (0–32 V) · 2× DO (1 A, protected) |
| Supply voltage | 12–24 V DC · ISO 7637-2 transient protection |
| Cold-crank ride-through | To 6 V / 100 ms |
| Deep-sleep draw | ≈500 µA, wakes on CAN activity |
| Operating temp | −40 to +85 °C |
| Ingress rating | IP67 (mated) |
The telemetry portal is a SaaS product — included with select Actium kits, or purchased and used entirely on its own.
Custom reports
Build the report your ops team actually needs — duty cycles, energy per route, uptime — and schedule it straight to their inbox.
Alerting
Threshold and anomaly alerts on any decoded signal — fault codes, temperatures, state of charge — delivered by email or webhook.
SaaS, yours either way
No servers to run. The portal is included with select Actium kits, and available as a standalone subscription for any fleet.
With an Actium kit
Pre-wired and VCU-integrated on every kit we ship — telemetry from the first key-on, with portal access included on select kits.
In your own vehicle
A standalone unit that speaks standard CAN. Integrate it into your own platform with our harness documentation and applications-engineering support.
